MR20 Wearable RFID Reader

MR20 Wearable RFID Reader Specification

Color
Yellow

Material
Plastic

Weight
64 Grams (g)

Usage
Warehouse Management, Assets tracking, Inventory Management, Logistics Management

Dimension (L*W*H)
50 x 62 x 19 Millimeter (mm)

Technology
UHF RFID

Power Supply
Battery

MR20 Wearable RFID Reader Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10000 Pieces Per Month

Delivery Time
2-10 Days

About MR20 Wearable RFID Reader

The MR20 Wearable RFID Reader is the perfect solution for your security needs. With its digital technology, users can easily identify and track RFID tags with a frequency range of 920-925 Megahertz (MHZ). Weighing only 64 grams and measuring 50 x 62 x 19 millimeters (mm), this device is lightweight and compact. Its plastic material and temperature range of -20 C to +50 C Celsius (oC) make it durable and suitable for any environment. Available in yellow, blue, and gray, this device is not only functional but also stylish. The MR20 Wearable RFID Reader is battery-powered, making it convenient for on-the-go use. It is perfect for security purposes, such as tracking inventory or personnel.

Physical Characteristics
Dimensions	50 x 62 x 19mm / 1.97 x 2.44 x 0.75 in.
Weight	64 g / 2.26 oz. ( with glove: 90 g / 3.17 oz. )
Power	1200 mAh ( removable )
Keypad	ON/OFF, SCAN
Indicator LED	Red indicator will be ON when charging; Blue indicator will be ON when device has been fully charged; Green indicator will be ON when battery is higher than 20%; Green indicator will flash when battery is lower than 20%; Bluetooth is not paired when bluetooth indicator is OFF; Bluetooth is paired when bluetooth indicator is ON
Colour	Yellow, Blue, Gray
Port	USB Type-C
Charging Current	5 V / 1.5 A
Charging Duration	1 hours
Communication
Bluetooth	Bluetooth Low Energy (BLE) 5.0
USB Type C	USB connection to realize data transfer

Developing Environment
SDK	Android / iOS SDK Supported
Security	RFID Encrypted Module ( reserve )
Performance
MCU	Cortex-M3 72MHz

User Environment
Operating Temp.	-20 °C to +50 °C
Storage Temp.	-40 °C to +70 °C
Humidity	5% RH - 95% RH non condensing
Drop Specification	1.2 m dropping on concrete
Sealing	IP65
UHF RFID
Engine	CM-3N module based on Impinj E310
Frequency	920-925 MHz / 902-928 MHz / 865-868 MHz
Protocol	EPC C1 GEN2 / ISO18000-6C
Antenna	Linear Polarized Antenna (-2.2dBi)
Power	0.5W (27dBm, support +19-27dBm adjustable)
Max Read Range	80 cm
Note	*Range depends on tags and environment
