UR4 Fixed RFID Reader

UR4 Fixed RFID Reader Specification

Weight
329 Grams (g)

Material
Aluminium alloy

Usage
Warehouse Management, Assets tracking, Inventory Management, Logistics Management

Dimension (L*W*H)
102.8 mm(L) x 102.8 mm(W) x 28 mm(H) Millimeter (mm)

Technology
UHF RFID

Power Supply
Electric

UR4 Fixed RFID Reader Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
2-10 Days

About UR4 Fixed RFID Reader

The UR4 Fixed RFID Reader is a high-quality security device made with durable Aluminium alloy material. It is designed to provide reliable and efficient security solutions for various industries. This reader operates on a frequency range of 865-868 Megahertz (MHZ) and can withstand temperatures ranging from -25 C to 65 C Celsius (oC). With its compact size of 102.8 mm(L) x 102.8 mm(W) x 28 mm(H) Millimeter (mm) and lightweight of 329 Grams (g), it can be easily installed in any location. The UR4 Fixed RFID Reader is powered by electricity and comes in a sleek black color that complements any environment.

Physical Characteristics
Dimensions	102.8 mm(L) x 102.8 mm(W) x 28 mm(H)
Weight	329 g / 11.6 oz.(without antenna)
Material	Aluminium alloy
Input Voltage	DC 9V 12V
Standby Current	< 30mA
Comm Interface	RS-232 / RJ45
GPIO	2 channel input optical coupling, 1 channel output electric relay, 1 channel output optical coupling (in reserve)
Baud Rate	115200 bps
Cooling Mode	Air cooling
Work Current	800mA +/-5% @ DC 12V Input
Ethernet interface	10/100 Base-T Ethernet (RJ45)
Power Supply	POE (802.3af 13W) (Optional) POE+ (802.3at 25.5W) (Optional)
Developing Environment
SDK	Windows, Linux, Android

User Environment
Operating Temp.	-25 C to 65 C
Storage Temp.	-40 C to 85 C
Humidity	10%- 95%
UHF RFID
Engine	CM710-4 module based on Impinj E710
Frequency	865-868 MHz / 920-925 MHz / 902-928 MHz
Protocol	EPC global UHF Class 1 Gen 2 / ISO 18000-6C
Antenna	Supporting a variety of antennas, such as 6dBic, 9dBic
Output Power	1W (30dBm, support +5~+30dBm adjustable) 2W Optional (33dBm, support +10~+33dBm adjustable, for Latin America, etc.)
Output Power Precision	+/- 1dB
Output Power Flatness	+/- 0.2dB
Receive Sensitivity	< -84 dBm
RSSI	Supported
Ambient Temp Monitor	Supported
Fastest Read Rate	900+ tags/sec
Antenna Detector	Supported
Antenna Port	4 channel 50 SMA port
